Type

JL055B

JL055M

JL055ZB

JL055ZM

Display digit size

H×W: 4mm×2mm

Ambient temperature

-10℃～+50℃

Max. capacity of accumulative temperature

99999

Transmission ratio

1:1

Counting speed

≤250 times/min

Pulling angle

Max. pulling angle=41°, Min. pulling angle=37°

Torque

≤8 N·cm

Pull direction

Feature

Pulling at the right side, the arm turns clockwise

Pulling at the right side, the arm turns clockwise

Pulling at the left side, the arm turns clockwise

Pulling at the left side, the arm turns counter-clockwise

Weight

约72g

This product can be designed and manufactured according to customer’s needs.
